Frame
100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, flat-mount disc, UDH, 142x12 mm thru axle
Fork
Domane AL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle
Weight
56 - 10.55 kg / 23.26 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
Shifter
Shimano Claris ST-R2000-R, 8 speed
Front derailleur
Shimano Claris R2000, 31.8 mm clamp
Rear derailleur
Shimano Claris R2000, medium cage, 34T max cog
Crank
Shimano RS200 50/34
Bottom bracket
Shimano UN300, 68 mm, threaded cartridge, 110 mm spindle
Cassette
Shimano HG31, CS-HG31, 11-32, 8 speed
Chain
Shimano Sora HG71, 8 speed
Max. chainring size
1x: 50T, 2x: 50/34
Hub front
Formula RX-512 alloy, 6-bolt, 100x12 mm thru axle
Skewer front
Bontrager Switch thru axle, removable lever
Hub rear
Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear
Bontrager Switch thru axle
Rim
Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32 mm
Max tyre size
38mm without mudguards, 35mm with mudguards
Saddle
Verse Short, steel rails, 145 mm width
Seatpost
Bontrager Comp Alloy
Handlebar
Bontrager Comp Alloy
Handlebar tape
Bontrager Supertack Perf tape
Stem
Bontrager Elite 31.8mm
Brake
Tektro C550 mechanical disc brake, dual piston, flat mount
Brake rotor
Tektro wave, 6-bolt, 160 mm
Rotor size
Max brake rotor sizes: 160 mm front and rear
